Galbiati Prima Class B Autoclaves – 18L/23L

Speed: complete cycle in just 30′
– Complete cycle in just 30′
– Our R&D department has created a product capable of halving sterilization times, reducing them to just 30 minutes.
– Complete cycle hollow at 134° in less than 30 minutes.

Stainless steel
We have designed a cutting-edge machine thanks to the search for excellent components and latest generation electronics. Stainless steel gives Prima an innovative and elitist design, and at the same time compliance with hospital standards.

Internal circuit washing cycle
The washing cycle of the internal circuits extends the life of the autoclave, reducing the need for technical interventions. No chemical additives, only distilled water from the stainless steel clean water tank, in just 4 minutes!

TECHNICAL SPECIFICATIONS


– Tensione nominale: a.c. 220V-230V, 50Hz
– Rated power: 18L 1500VA, 23L 1700VA
– Material: stainless steel (medical grade)
– Maximum working pressure: 2.5 bar Minimum working pressure: -0.9 bar
– Maximum temperature: 145°C
– Chamber volume: 18L (Φ245×320mm) 23L (Φ245×450mm)
– Cargo size: 18L (198×204×285) 23L (198×204×385)
– Maximum load weight: 18L (3.07kg/cm2) 23L (3.21kg/cm2)
– Working pressure/temperature: 1.10~1.30bar / 121°C~122°C; 2.10~2.30bar / 134°C~135°C
– Water volume for one cycle: 0.16L (min) 0.18L (max) 2.10~2.30bar / 134°C~135°C
– Water volume for one cycle: 0.16L (min) 0.18L (max) 2.10~2.30bar / 134°C~135°C : 0,16L (min) 0,18L (max)

PERFORMANCE

– Rapid cycles (26 minutes for HOLLOW 134°C)
– Limited water consumption
– Automatic water drain
– 100% stainless steel
– Electronic control of water quality
– Easy to place system
– GKE propeller compliance test
– Integrated printer and data saving system via usb
– 24 months warranty

ACCESSORIES

– Simple and intuitive control panel
– Visualization of the cycle diagram for real-time work control
– Quick and easy connection to water supply and drainage
– 4 treys rack, which can also be used as 3 treys rack
– Personalized USB stick for cycles on P
– CD installer for saving cycles on PC

Brochure
